E789 UNIT
Function Time/Seconds
1. Fill with hot water and Detergent concentrate 60
2. Fill with hot water only 30
3. Ultrasonic cleaning 600
4. Drain 180
5. Fill 90
6. Ultrasonic 60
7. Ultrasonic/Rinse 60
8. Ultrasonic 60
9. Ultrasonic/Rinse 60
10. Ultrasonic 60
11. Drain 150
12. Drain, Dryer, Fan 420
13. Drain, Fan 120
14. Buzzer 5
TOTAL 1835 seconds
(30 ½ minutes)
9. WATER CONSUMPTION
In the program, 5 gallons of water are used on the initial fill cycle with an
additional 12 gallons used in the fill-rinse steps, C to H, for a total of 17 gallons
of hot water used per cycle.
If any changes in the rinse programs are required, consult the manufacturer.
10. DRYING
Incoming air is heated in the tank cover to 160° F and forced by the fan
through the tank chamber before exhausting through the tank cover.
CAUTION: Do not touch the cover during the drying cycle because some areas
will be hot. Also, NEVER place any towel or obstruction over the fan intake on
cover. After 7 minutes of hot air drying, the parts are left in the tank for 2
minutes to allow some cooling to take place before handling. The air
temperature during the hot air drying can be increased or decreased by
adjusting a thermo-switch located in dryer cover at hot air exit. Please contact
manufacturer for more details.
