27
English
Specifications
Speaker output
Rated output ...................................... 30 W + 30 W (8 Ω)
60 W + 60 W (4 Ω)
Total harmonic distortion .....................................0.006%
(1 kHz, 8 Ω, 30 W)
Frequency response ................................. 10 Hz – 100 kHz
(+0/−3.0 dB at 1W output)
S/N ratio ............................................... 104 dB (IHF-A)
Damping factor ...................................................370
Minimum compatible impedance ................................4 Ω
Speaker output connectors ...............................2 pairs (L/R)
(screw type)
Inputs
XLR connectors ...........................................2 pairs (L/R)
RCA connectors ..........................................4 pairs (L/R)
PHONO connectors ........................................1 pair (L/R)
(MM/MC switchable)
EXT. PRE IN connectors ....................................1 pair (L/R)
Input impedance
XLR, RCA ....................................................10 kΩ
PHONO (MM) ................................................47 kΩ
PHONO (MC) ................................................100 Ω
EXT. PRE IN ..................................................47 kΩ
Outputs
XLR connectors ............................................1 pair (L/R)
(combined PRE OUT and REC OUT)
RCA connectors ...........................................1 pair (L/R)
(combined PRE OUT and REC OUT)
PHONES jack .......................................................1
Output impedance
XLR, RCA ....................................................100 Ω
PRE OUT S/N ratio (at 1V output)
XLR, RCA input .............................................110 dB
PHONO (MM) input ..........................................93 dB
PHONO (MC) input ..........................................75 dB
Gain
Preamplifier ...............................................24.5 dB
(when VOLUME at maximum)
Power amplifier. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 dB
Tone controls
BASS ...............................................±12 dB (63 Hz)
MIDDLE ...........................................±12 dB (630 Hz)
TREBLE ............................................±12 dB (14 kHz)
General
Power supply
Model for Europe/Hong Kong .....................AC 230 V, 50 Hz
Model for USA/Canada ............................AC 120 V, 60 Hz
Power consumption
Model for Europe/Hong Kong ..............................290 W
290 W (when no signal)
Model for USA/Canada .....................................290 W
215 W (when no signal)
External dimensions
445 × 191 × 468 mm (17 5/8” × 7 5/8” × 18 1/2”)
(W × H × D) (including protrusions)
Weight ..............................................32 kg (70 5/8 lb)
Operating temperature ................................+5°C to +35°C
Included accessories
Power cord × 1
Remote control (RC-1301) × 1
Batteries for remote control (AAA) × 2
Felt pads × 4
Owner’s manual (this document) × 1
Warranty card × 1
o Specifications and appearance are subject to change without
notice.
o Weight and dimensions are approximate.
o Illustrations in this Owner’s Manual might differ slightly from pro-
duction models.
