Making connections
V
Precautions when making connections
o Complete all other connections before connecting power plugs to power outlets.
o Read the owner’s manuals of all devices that will be connected, and follow their
instructions.
A
LLRR
B
C
D
E
F
G
Digital output can be turned on/
off (page 26).
The polarity of the XLR connec-
tors can be set so that either 2 or
3 is HOT (page 26).
RCA audio cables
XLR cables
USB cable
Connect using a set of
only one type.
RCA coaxial digital cable
Optical digital cable
Included power cord
RCA coaxial digital cable
BNC coaxial cable
Stereo amplifier
Computer
Other digital device
(DA converter, AV amplifier,
recorder, etc.)
Equipment
with digital
audio output
Equipment with dig-
ital audio output
Device that outputs
clock signal (G-01,
G-02, etc.)
DIGITAL IN
(COAXIAL)
DIGITAL IN
(XLR)
DIGITAL OUT
(COAXIAL)
DIGITAL OUT
(OPTICAL)
CLOCK SYNC OUT
Audio input
(LINE IN, etc.)
XLR digital cable
