Specifications
Playable disc types
Super Audio CD, CD (including CD-R and CD-RW)
Analog audio outputs
Connectors .................................XLR (2 channels) × 1 pair
RCA (2 channels) × 1 pair
Output impedance ........................................XLR: 40 Ω
RCA: 10 Ω
Maximum output level (at 1kHz, 10kΩ load) .............XLR: 4.8 Vrms
RCA: 2.4 Vrms
DSD playback is −3 dB when DSDF> OFF
When Super Audio CD, XLR output
Frequency response .......................... 5 Hz to 40 kHz (−3 dB)
S/N ratio
K-01X .........................................................117 dB
K-03X .........................................................116 dB
Distortion
K-01X ................................................0.0006% (1 kHz)
K-03X .................................................0.001% (1 kHz)
Digital audio output
XLR connector × 1 ................................3 Vp-p (into 110 Ω)
RCA connector × 1 ..............................0.5 Vp-p (into 75 Ω)
Digital audio input
RCA connector × 1 (input impedance 75 Ω) ..................0.5 Vp-p
Optical digital connector × 1. . . . . . . . . . . . . . . −24.0 to −14.5 dBm peak
USB-B connector ...................................USB2.0 standard
Clock sync input format
Connector ...................................................... BNC
Supported input frequencies (±15 ppm)
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz,
176.4 kHz, 192 kHz, 10 MHz,
22.5792 MHz, 24.576 MHz
Input impedance ................................................75 Ω
Input level ..................Rectangle wave: equivalent to TTL levels
Sine wave: 0.5 to 1.0 Vrms (50 to 75 Ω)
General
Power supply
Model for Europe/Hong Kong .......................AC 230 V, 50 Hz
Model for USA/Canada ..............................AC 120 V, 60 Hz
Model for Korea .....................................AC 220 V, 60 Hz
Power consumption
K-01X ...........................................................27 W
K-03X ...........................................................25 W
External dimensions (W × H × D) ...............445 × 162 × 438 mm
(17 5/8" × 6 1/2" × 17 1/4")
(including protrusions)
Weight
K-01X ...............................................31 kg (68 3/8 lb)
K-03X ...............................................28 kg (61 3/4 lb)
Operating temperature ...............................+5°C to +35°C
Operating humidity ...................5% to 85% (no condensation)
Storage temperature ................................−20°C to +55°C
Included accessories
Power cord × 1
Remote control × 1
K-01X .......RC-1315
K-03X .......RC-1301
Batteries (AAA) × 2
Felt pads × 3
Owner’s manual (this document) × 1
Warranty card × 1
o Design and specifications are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations in this manual might differ slightly from production
models.
