Esoteric P-03 - Block Diagram

32
RF Amp
Motor
Driver
Super Audio CD
Back End DSP
DSD Decoder
PCM Audio DSP
Front End DSP
MCK
MCK
VRDS-NEO
メカニズム
CD
(DVD-Audio)
Digital
Audio I/F
Transmitter
Digital
Audio I/F
Transmitter
XLR 1
(L)
RCA
Digital
Audio I/F
Transmitter
XLR 2
(R)
ES-LINK
Encoder
DSRLL III
Upconverter
(L/R)
MCK
PCM-DSD
Converter
PCM
DSD
Word IN
PLL
Master
Clock
X'tal
MCK
WORD IN
PCM
1394
Transmitter
i.LINK(AUDIO)
(IEEE1394)
DSD
PCM
DSD
60958
60958
Block Diagram
VRDS-NEO
