System PSU
Seperator
+V -V E L N
240vAC
No cable
or connection
polarity
Power supply
to be with-in
100 meters
of monitor
Cable run between
door station and
furthest monitor
should not exceed
150 meters
Each monitor requires the following:
Set up as a Master or Slave
Set up with a unique
Address ID: 01-32
Refer to the monitor’s specific
Set up guide
1
2
Each branch controller requires the
following;
Adjusted dipswitch settings;
When in use with monitors
When in use with door stations
The branch controller at the end of
the line has the impedance switch
to ON the indication LED will
turn amber
1
2
123
ON
123
ON
The dipswitches are accessible
on the rear of the door station
BUS
When using multiple door
stations ensure that each unit
has a seperate Address ID
Branch
Controller
Branch
Controller
Address ID
01
Address ID
04
Address ID
02
Address ID
03
System PSU
BUSBUS
BUS
BUS
BUS
BUS
Branch
Controller
Address ID
29
Address ID
32
Address ID
30
Address ID
31
Branch
Controller
BUSBUS
BUS
Address ID
01
Address ID 01
Address ID 02
Address ID
02
Address ID
03
Address ID
04
To Next Page
