ESP DVR8iP - Front Panel Layout

4
No. FUNCTION LED COLOUR
1 Main power on Blue
2 Alarm Indication Blue
3 HDD/Record Indication Blue
4 Escape N/A
5 Navigation keys for Menu N/A
1 2 3
4
5
Front Panel
Connection Diagram
