ADDITIONAL INFORMATION
Trouble Shooting Guide
After trying the methods below, if the problem persists, contact your nearest local
dealer
Unit totally dead (Power Lamp OFF)
-The power cord is not properly inserted in the AC outlet, or the AC is not supplied
-The power ON/OFF switch is in the OFF position
Cannot gain enough volume when talking to other units
-Adjust VOLUME with volume selector
Poor picture appears on the screen
-Make sure if lens of outdoor camera is clean
Can call and communicate, however, there is no audio signal
-Defective Camera
Enterview 3 / 3V / 3C / 3VC 16|17
Specifications
Enterview 3 / 3V / 3C / 3VC (Main unit)
Enterview 3 / 3C (Metal Camera)
The depth of camera on the table indicates from wall surface after installation
Remark Specification
Voltage Requirements 90~250V AC, 50/60 Hz(Smps)
Power Consumption
B/W Maximum 30VA, Stand by 5VA
Color Maximum 28VA, Stand by 5VA
Monitor Screen B&W Flat 4 Flat type / Color 4 TFT-LCD
Maximum Wiring Distance 50m/165 feet (22 AWG, 0.65mm 4wire)
Audio Communication Duplex handset
Extensions Monitor or Image memory
Environment
Temperature -10 C to +40 C
Humidity Below 90% (relative)
Size
Dimension
188W 208H 60D(mm) / 7-2/5W 8-1/5H 2-1/3D(Inches)
Weight 1.3 kg (2.86 Ibs) / 1.0 kg (2.20 Ibs)
Installation Surface Mount Type
Remark Specification
Power Source DC 13V (supplied from Monitor)
Power Consumption DC 13V, 0.25A
Display Input 1Vp-p/75, Composite CCIR/EIA, PAL/NTSC
Minimum Illuminance 0.1 Lux(B/W) / 3 Lux(Color)
Environment
Temperature -10 C ~ 40 C
Humidity Below 90% (relative)
Size
Dimension
120W
184H 16D(mm) / 4-3/4W 7-1/4H 3/5D(Inches)
Weight 0.5kg / 1.10 Ibs
Installation Flush Mount Type
