Basic guide Introduction Bench-top type temperature (and humidity) chamber
ESPEC CORP. | 19
No. Accessory/Part Use Q’ty.
Check if
included
③
Humidifying tray
drain hose
I.D. 8 mm hose with quick detachment plug.
Use to drain the humidifying tray and wick
pan. (SH only)
1
④
Water tank level
sensor tank drain
hose
I.D. 5 mm hose with quick detachment plug.
Use to drain the water tank level sensor tank.
(SH chambers only)
1
⑤
Connector (For
temperature
[humidity] recorder
terminal
)
Use to detect dry-bulb temperature (test area)
and relative humidity. (Relative humidity
detected with SH only.)
SU 1
SH 2
⑥
Terminal plug
(For external
interface)
Use to connect the chamber to the external
devices.
(SH/SU-222,242, 115V AC only)
7
⑦
Power plug
Use to connect socket for 20A. (SH/SU-
262,100V AC only)
1
⑧
Wet-bulb wick
Box of 24 wet-bulb wicks and 1 dropper
(SH only)
1
⑨
Cartridge fuse
(Protects
instrumentation
circuits and parts.)
SH/SU-222, 242
100, 220, 230V AC B type 250V 7A
115V AC NEC spec. UL-compliant 250V
0.75A, 0.5A, 0.06A
1
1 each
SH/SU-242-5 B type 250V 7A, 6A 1 each
SH/SU-262, 642, 662
Except NEC spec. B type 250V 7A, 6A
NEC spec. 200V UL-compliant 250V 1A
0.06A
1 each
2
1
⑩
Class CC fuse
(Protects
instrumentation
circuits and parts.)
SH/SU-222, 242
115V AC NEC spec.
UL-compliant 600V 7A, 6A, 2A 1 each
SH/SU-262, 642, 662
115V AC NEC spec.
UL-compliant 600V 7A, 6A, 4A, 2A 1 each
⑪
Breaker handle
cover
Protects against erroneous operation.
Attaches to the breaker when the breaker is
off.
1
⑫
Stylus pen
Use for comfortable touchscreen operation.
1
⑬ Operation manual
Provides the instructions for correct operation
of the chamber. (CD, Installation guide)
1 set
⑭ Warranty card
Warranty information for the product.
1
