USB-to-UARTPort
AMicro-USBportusedforpowersupplytotheboard,aswellasthe
communicationwiththeESP32-S3chipviatheon-boardUSB-to-
UARTbridge.
BootButton
Downloadbutton.HoldingdownBootandthenpressingReset
initiatesFirmwareDownloadmodefordownloadingfirmware
throughtheserialport.
ResetButton Pressthisbuttontorestartthesystem.
ESP32-S3USBPort
ESP32-S3full-speedUSBOTGinterface,compliantwiththeUSB1.1
specification.
USB-to-UARTBridge SingleUSB-to-UARTbridgechipprovidestransferratesupto3Mbps.
RGBLED AddressableRGBLED,drivenbyGPIO48.
3.3VPowerOnLED TurnsonwhentheUSBpowerisconnectedtotheboard.
KeyComponent Description
StartApplicationDevelopment
Beforepoweringupyourboard,pleasemakesurethatitisingoodconditionwithnoobvioussignsof
damage.
RequiredHardware
ESP32-S3-DevKitC-1
USB2.0cable(Standard-AtoMicro-B)
ComputerrunningWindows,Linux,ormacOS
 Note
BesuretouseanappropriateUSBcable.Somecablesareforchargingonlyanddonotprovidethe
neededdatalinesnorworkforprogrammingtheboards.
SoftwareSetup
PleaseproceedtoGetStarted,whereSectionInstallationStepbyStepwillquicklyhelpyousetupthe
developmentenvironmentandthenflashanapplicationexampleontoyourboard.
ContentsandPackaging
Retailorders
Ifyouorderafewsamples,eachboardcomesinanindividualpackageineitherantistaticbagorany
packagingdependingonyourretailer.
Forretailorders,pleasegotohttps://www.espressif.com/en/company/contact/buy-a-sample.
