Espressif ESP32-S3-DevKitC-1 User Manual

CONFIDENTIAL
3 RX I/O/T U0RXD,GPIO44,CLK_OUT2
4 1 I/O/T RTC_GPIO1,GPIO1,TOUCH1,ADC1_CH0
5 2 I/O/T RTC_GPIO2,GPIO2,TOUCH2,ADC1_CH1
6 42 I/O/T MTMS,GPIO42
7 41 I/O/T MTDI,GPIO41,CLK_OUT1
8 40 I/O/T MTDO,GPIO40,CLK_OUT2
9 39 I/O/T MTCK,GPIO39,CLK_OUT3,SUBSPICS1
10 38 I/O/T GPIO38,FSPIWP,SUBSPIWP
11 37 I/O/T SPIDQS,GPIO37,FSPIQ,SUBSPIQ
12 36 I/O/T SPIIO7,GPIO36,FSPICLK,SUBSPICLK
13 35 I/O/T SPIIO6,GPIO35,FSPID,SUBSPID
14 0 I/O/T RTC_GPIO0,GPIO0
15 45 I/O/T GPIO45
16 48 I/O/T GPIO48 ,SPICLK_N,SUBSPICLK_N_DIFF
17 47 I/O/T GPIO47,SPICLK_P,SUBSPICLK_P_DIFF
18 21 I/O/T RTC_GPIO21,GPIO21
19 20 I/O/T RTC_GPIO20,GPIO20,U1CTS,ADC2_CH9,CLK_OUT1,USB_D+
20 19 I/O/T RTC_GPIO19,GPIO19,U1RTS,ADC2_CH8,CLK_OUT2,USB_D-
21 G G Ground
22 G G Ground
No. Name Type Function
1
P:Powersupply;I:Input;O:Output;T:Highimpedance.
2
UsedtodrivetheRGBLED.
PinLayout
2

Espressif ESP32-S3-DevKitC-1 Specifications

General

Brand	Espressif
Model	ESP32-S3-DevKitC-1
Category	Microcontrollers
Language	English
