5
6
7
8
Screw the other part with the 4 screws ref CV6273 (M4x16mm).
Position the screen from above as shown below.
Screw the security screw.
Adjust the screen angle as needed.
USER MANUAL > INSTRUMENT
13 Vision-C 600 - Polarized visual chart system > V1- 02-2021 (VRSQSE)
