Front face
1. Polarization LCD
2. IR sensor
3. White LED (test Maddox)
Rear face
1. Aeration
2. Speaker
3. Fixation zone
4. Aeration
Connection
1. Power switch ON/OFF
2. Power IN DC 12V
3. RH45 Lan
4. USB1
5. USB2
