Essilor Instruments Vision-C 600 User Manual

LCD type: 24 Inch IVO TFT LCD / optical polarizing glass type
Resolution: 1920 x 1080 pixels
Chart window size:
Lenght: 293.2 mm
Width: 521.3 mm
Brightness: Max 250 cd / m²
View distance: 3 m ~ 8 m (0.25 step adjustment)
Memory card: SD card (8 GB)
Audio output: Mono 4W Max
Power source:
12V 5A (power adaptor)
Model: GSM60A12-P1J
Power consumption: Less than 60VA
Communication:
Wire: Ethernet
Wireless: IR DA Communication
Dimension and weight:
Length: 393.6 mm
Width: 612 mm
Depth: 71.3 mm
Total weight: 7.9 Kg
LEDs specifications
Visible white LED:
Color: white
Chromaticity CCT: 5000 K
Flux: 35.9 lm
Class: NC
Infra-red LED:
Color: IR
Wavelength: 850 nm
Radiant intensity: 1000mW/sr
Class: 2
USER MANUAL > TECHNICAL DATA
Vision-C 600 - Polarized visual chart system > V1- 02-2021 (VRSQSE) 38
