P/N P-047550-1726-EN • REV 08 • ISS 05AUG16 7 / 8
Specifications
Operating voltage range 15.20 to 19.95 VDC
Current See Table 2 on page 8
Output ratings (special
applications)
24 VDC
25 VRMS audio
70 VRMS audio
End-of-Line Resistor
Circuit capacitance
2 A
50 W
35 W
47 kΩ, UL/ULC listed
0.1 µF max.
Initiating device circuit (IDC)
Circuit resistance
Circuit capacitance
Alarm current
Operating voltage
50 Ω max. (25 Ω per wire)
0.1 µF max.
17 mA max.
16.0 to 24.0 VDC
Maximum line impedance Refer to the fire alarm panel
installation manual
Ground fault impedance 10 kΩ
Compatible smoke detectors Refer to the fire alarm panel
compatibility list.
Two-wire smoke ripple voltage 2 VAC
EOLR part numbers
15 kΩ
22 kΩ
47 kΩ
EOL-15
EOL-22
EOL-47
Circuit designation
Signaling line circuit
Notification line circuit
Initiating device circuit
Telephone riser circuit
Class A, Style 6 or Class B, Style 4
Class A, Style Z or Class B, Style Y
Class A, Style D
Class B, Style 4
Contact ratings (pilot duty) 24 VDC at 2 A
120 VAC at 0.5 A
Contact type Form C, programmable
Compatible electrical boxes 2-1/2 in. (64 mm) deep double-gang
box;
4 in. square box, 1-1/2 in. (38 mm)
deep, with a double-gang cover
LPCB/CPR electrical box
Requirements
Minimum size W × H × D
Plastic box with cover plate, no gaps
or unused holes
3.5 × 3.5 × 1.5 in. (85 × 85 × 38 mm)
Wire size 12 to 18 AWG wire (1.0 to 4.0 mm)
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93%, noncondensing
Storage temperature range −4 to 140°F (−20 to 60°C)
Regulatory information
FCC compliance This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
North American
standards
UL864, CAN/ULC-S527
EN 54 EN 54-18: 2005 Input/output devices
EU compliance
CPR certificates 0832-CPR-F0335
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information, see:
www.recyclethis.info.
Contact information
For contact information, see www.est-fire.com.
