Table 2: Personality code characteristics

Personality code Mode of operation Standby current Activated current EOL resistor

1, 2, 3, 4, 18 Class B initiating device circuit 458 µA 700 µA 47 kΩ

8 Form C dry contact relay 127 µA 120 µA N/A

9, 10, 11, 12 Class A initiating device circuit 307 µA 450 µA N/A

13, 14, 20, 21 Two-wire smoke detectors and initiating devices 3.1 mA

(from 3rd wire)

N/A Class A: 22 kΩ

Class B: 15 kΩ

N/A First UM module to go into alarm (Class A or B) N/A 12 mA smoke detector

17 mA contact closure

N/A

N/A Each subsequent UM to go into alarm N/A 100 µA (from data line) N/A

15, 16 Class A or B notification appliance circuit 317 µA 140 µA Class A: N/A

Class B: 47 kΩ
