6. Technical data and description
6.1 Small dust extractor models
6.1.1 TK
Model:
(see model plate)
TK-4
TK-6
TK-H
TK-2.2
Max. air volume
[m³/h]
300
450
300
300
Max. vacuum
[Pa]
1.100
1.400
24.000
21.000
Connection voltage
[V]
400/230*
400
Nominal frequency
[Hz]
50
Drive output
[kW]
0,55
2,2
RPM
[1/min]
2.800
Filter area
[m²]
1
Connection
diameter
[mm]
60
80
50
Dimensions
(L/W/H)
[mm]
400x400x590
400x630x
590
930x460x
655
Total depth
[mm]
600
-
900
Weight
[kg]
40
60
105
Environmental
conditions
[°C]
540
Max. air humidity
[%]
approx. 60
Production year
See model plate
*Custom design for AC current
6.1.2 OM
Model:
(see model plate)
OM-8
OM-10
OM-12
OM-12S*
Max. air volume
[m³/h]
500
600
800
Max. vacuum
[Pa]
1.600
1.500
1.800
Connection voltage
[V]
400
Nominal frequency
[Hz]
50
Drive output
[kW]
0,55
1,1
RPM
[1/min]
2.800
Filter area
[m²]
2,4
Connection diameter
[mm]
80
100
150
Dimensions (L/W/H)
[mm]
720x630x
1.120
740x610x
1.080
740x610x
1.150
720x600x
1.420
Total depth
[mm]
670
Weight
[kg]
60
65
70
Environmental
conditions
[°C]
540
Max. air humidity
[%]
approx. 60
Production year
See model plate
*Larger dust collection drawer
