10.2.2 OM / OMF model devices
1. Remove the fan housing, including the motor and fan
2. Undo the four latches and remove the two screws on the blower box.
3. Loosen the 8 nuts on the filter fittings.
4. Remove the tapping device by loosening the four screws (front side of the
machine).
5. Loosen the 12 nuts on the filter frame and remove the filter.
6. Remove the filter fitting by loosening the screws.
To reinstall the filter, follow the same procedure in reverse.
The people assigned to disposal work must be instructed on the aspirated
toxic materials and wear a breathing protection mask with a class P3
particle filter, as well as protective gloves. All distractions by uninvolved
persons must be prevented.
11.1 Disposing of collected dust materials
To dispose of the collected material, remove the dust collection drawer from the
device by removing both knurled nuts. Now the dust collection drawer can be
pulled out.
Dispose of the dust contained in the drawer in keeping with local regulations.
Reinsert the emptied container and tighten the knurled nuts again. The device is
now ready to operate again.
11.1.3 OM / OMF model devices
For removing the collected material, the dust collection container’s two latches (on
the underside of the device) must be undone. Now the container can be pulled
out. The collected material must be discarded in compliance with local regulations.
Reinsert the emptied container and lock the latches again. The device is now
ready to operate again.
