13. Device diagram
With the model information, request the replacement parts you need from
the
ESTA replacement part service: +49 (0) 7307 804 - 0
Small dust extractors of models TK, OM and OMF
Dust collection drawer
(knurled nut attachment)
Bag filter on TK models
Screw lid for filter
replacement
Fan housing
(latch mounting)
TK-4; TK-6
TK-H; TK-2.2 (internal motor)
OMF-8; OMF-10; OMF-12
Bag filter on OM / OMF models
Insertable spark protection
pad
(knurled nut attachment)
OM-8; OM-10; OM-12
Dust collection drawer
(latch mounting)
Hand crank for filter cleaning
