4.5.2Step 2. Connect AC Cables of Microinverter
A). Plug the AC connector of the first microinverter into the connector of the second microinverter
to form a continuous AC branch circuit.
B). Install the AC end cap on the open AC connector.
*Note: The length of AC cable on microinverter is roughly 2 m, if the distance between two
microinverters is more than 2m, please use an AC extension cable between two microinverters (as
shown in the picture below).
