[Pellet store] function block Configuration parameter
6.8 [Pellet store] function block
Parameters to be set
Set or check the following parameters.
Detailed descriptions of the parameters are provided
below.
Explanation of [Type of store]
This parameter is used to set the type of pellet
conveying system for the pellet store. This setting is
also used to adjust the electricity settings for the drive
of the pellet conveying system.
The following options are available:
• Standard screw
• ETAbox with conveyor screw
• GEOplast underground tank WITH ABS controller
• Suct. lance w/ vibr. mot.
• Mole, room < 2x2 m
• Mole, room > 2x2 m
• Conveyor w/o motor (single suction head, lance)
•Misc.
• GEOplast underground tank WITHOUT ABS
controller
• Mole E3
If you select the [Misc.] type, you must adjust the
electricity settings manually.
Explanation of [Max. current], [Min. current] and
[NominCurr]
You only have to adapt the electricity settings for
the drive of the pellet conveying system if the
[Misc.] type was selected during configuration. For all
other types, there is already a factory setting.
Define the electricity settings using the parameters
[Max. current], [Min. current] and [NominCurr].
Compare them with the data on the drive type plate,
and adjust if necessary.
Type of store
Outputs
Discharge screw
Max. current
Min. current
NominCurr
