3．AC Voltage Measurement
Ac line voltage measurement can't exceed 600 V.
Connect P
(S)
and ES interface to test commercial AC
voltage, no need to connect C
(H)
and E interface.
AC voltage measurement refers to the general commercial AC
voltage measurement, pay attention to the difference between grounding
voltage, the meter can be used for testing below 600V AC line voltage.
As shown below: Firstly connect test wires with P(S), ES interface,
secondly connect test wires with tested line, then rotate FUNCTION
rotary switch to “EARTH VOLTAGE” and start testing, LCD will display
the test results.
