ETC Service Note
Congo™ jr Power Supply Replacement
Congo™ jr Power Supply Replacement Page 37 Electronic Theatre Controls, Inc.
Step 10: Remove the base cover and set aside.
Step 11: Locate the Power Supply and cut the zip tie around the large bundle of cable.
Step 12: Disconnect the motherboard power connector.
Step 13: Remove the 2 power connectors attached to the Power Supply.
Cut this zip tie
Motherboard Power Connector
Remove these 2
power connectors
To Next Page
