Etec EKEC Series - Product Brief Introduction; Technical Standard

Product description
1.3 Technical date
-04-
Cable type Socket type
EKEC1-C-T1/T2-1P EKEC1-C-T1/T2-3P EKEC1-S-T1/T2-1P EKEC1-S-T1/T2-3P
Power mode 1P+N+PE 3P+N+PE 1P+N+PE 3P+N+PE
Operation voltage AC230V±10%50Hz AC400V±10%50Hz AC230±10%50Hz AC400V±10%50Hz
Output current 10A、16A、20A、25A、32A、63A
Output voltage AC230V±10%50Hz AC400V±10%50Hz AC230±10%50Hz AC400V±10%50Hz
Output power 7.3KW/14.5KW 22KW/43.5KW 7.3KW/14.5KW 22KW/43.5KW
Cable length 5m 5m - -
Plug/socket standard (American standard / European standard)Type1/Type2
Additional function
(Optional)
1.RCMU leakage monitoring mode(0-20mA/0-200mA) 2.Non-contact IC Card
3.DLB current balance mode 4.Current sensor access mode(DC+12V Output 0-5V) 5.With LCD display
Communicationfunction(optional)
1 way RS485(Modebus-RTU)/RS232
Ambient temperature -40℃ ~+50℃
Humidity ≤ 85%
IP degree IP55
Cooling method Natural cooling
Installation method Portable type / wall mounted type / Column type
Weight
Overall dimension 357*245*123 357*245*123 357*245*123 357*245*123
Installation dimension
180*280 180*280 180*280 180*280
1.1 Product brief introduction
This product is a single or three-phase AC charging pile, which is mainly used for AC charging of electric
vehicles. The equipment adopts industrial design principles. The protection level of the whole machine
reaches IP55, with good dustproof and waterproof functions, and can be safely operated and maintained
outdoors. The AC charging pile is divided into two categories: with cable version and without cable version.
Model
speci󽗉cation
Technical date
EK EC P
- -
Blank:Without additional function and communication function
Additional function
1.RCMU leakage monitoring mode (0-20mA/0-200mA)
2.Contactless IC card
3. DLB current balance mode
4.Current sensor access mode (DC+12V Output 0-5V)
5.With LCD display
Communication function
1 Way RS485(Modebus-RTU)/RS232
Current:10A, 16A,20A, 25A, 32A,63A
1P:Single phase ,3P:Three phase
Plug/Socket:T1 American standard T2 European standard
S:Socket type C:Cable type
Product series: EC1 Single plug EC2 Double plug EC4 Series AC EV Charging Station
Company code
1.2 Naming rules
