Etec EKEC Series - EKEC4 Series Electric Vehicle AC Charging Pile

EKEC4 Series AC EV Charging Station
-06-
Cable type Socket type
EKEC4-C-T1/T2-1P EKEC4-C-T1/T2-3P EKEC4-S-T1/T2-1P EKEC4-S-T1/T2-3P
Power mode 1P+N+PE 3P+N+PE 1P+N+PE 3P+N+PE
Operation voltage AC230V±10%50Hz AC400V±10%50Hz AC230±10%50Hz AC400V±10%50Hz
Output current 10A、16A、20A、25A、32A、63A
Output voltage AC230V±10%50Hz AC400V±10%50Hz AC230±10%50Hz AC400V±10%50Hz
Output power 7.3KW/14.5KW 22KW/43.5KW 7.3KW/14.5KW 22KW/43.5KW
Cable length 5m 5m - -
Plug/socket standard (American standard / European standard)Type1/Type2
Additional function
(Optional)
1.RCMU leakage monitoring mode(0-20mA/0-200mA) 2.Non-contact IC Card
3.DLB current balance mode 4.Current sensor access mode(DC+12V Output 0-5V) 5.With LCD display
Communicationfunction(optional)
1 way RS485(Modebus-RTU)/RS232
Ambient temperature -40℃ ~+50℃
Humidity ≤ 85%
IP degree IP55
Cooling method Natural cooling
Installation method Portable type / wall mounted type / Column type
Installation dimension
128*178 128*178 128*128 128*128
Overall dimension 150*200*140 150*200*140 150*200*140 150*200*140
Weight
2.6kg 2.9kg 1.4kg 1.5kg
Model
speci󽗉cation
Technical date
Product description
1.1 Technical date
1.2 Overall installation drawing
