Etec EKEC Series - Communication Function; RS485 Communication Details

Register
address
number
Data description (power failure protection) Read and write Type of data Defaults
100 (Device address number) Read and write 16-bit integer 255
101 DLB maximum starting current Read and write 16-bit integer 9000
102 DLB maximum current (100.00A) Read and write 16-bit integer 10000
103 Reference current: DLB/current transformation ratio (100.00A) Read and write 16-bit integer 10000
104 Reference current calibration value input Read and write 16-bit integer 1270
105 Charging pile current transformation ratio 50-200A Read and write 16-bit integer
106 Charging pile current value correction 0-100.0A Read and write 16-bit integer
107 Charging pile voltage value correction 0-500.0V Read and write 16-bit integer
108 Charging pile power value correction 0-22000W Read and write 16-bit integer
109 Maximum output PWM duty cycle of charging pile Read and write 16-bit integer 90%
110 RCMU function selection 0 disabled 1 enabled, other values are selected by DIP switch Read and write 16-bit integer 3
111 RFID function selection 0 disabled 1 enabled, other values are selected by DIP switch Read and write 16-bit integer 3
112 Lock function selection 0 disabled 1 enabled, other values are selected by DIP switch Read and write 16-bit integer 3
113 Cable function version selection 0 disable 1 enable, other values are selected by DIP switch Read and write 16-bit integer 3
114 DLB function selection 0 disable 1 enable, other values are selected by DIP switch Read and write 16-bit integer 3
115 PID control parameter P of DLB Read and write 16-bit integer 100
116 PID control parameters of DLB I Read and write 16-bit integer 1
117 DLB PID control parameter D Read and write 16-bit integer 100
118-119 Controller ID number up to 9 digits Read and write 32-bit integer
120-139 spare Read and write
140 Software version Read only 16-bit integer 1002
141 Current working status: Corresponding status 0-13 Read only 16-bit integer
142 PWM value of cable speci󽗉cation Read only 16-bit integer
143
RCMU status 00 Not selected 01 Normal operation 02 Self-check failed 03 There is leakage in the charging circuit
Read only 16-bit integer
144 RFID status 00 not selected 01 IC card not operating 02 IC card closed 03 IC card open Read only 16-bit integer
145 Lock status 00 not selected 01 locked 02 unlocked 03 fault Read only 16-bit integer
146 The current current, the decimal place is determined by the value of the reference current Read only 16-bit integer
147 Current value of charging pile 0-200.0A Read only 16-bit integer
148 Current voltage value of charging pile 0-500.0V Read only 16-bit integer
149 Current power value of charging pile 0-22000W Read only 16-bit integer
150 Calibration value AD value of reference current Read only 16-bit integer
151 The PWM duty cycle corresponding to the current set by the rotary switch Read only 16-bit integer
152 Current output PWM duty cycle Read only 16-bit integer
153-160 spare Read only 16-bit integer
RS485 Communication description(Modbus-RTUmodel , Baud rate: 38400, 󽗉xed , address: 1-255default : 255(Broadcast address ))
Communication function
