3.4 Indicator light and working status description
No.
State
Code
LED Color LED State PE、CP、PP state
Controller
state
Remark
0 K Red
5Hz 󽗊ashing
Power self detect failed Fault--1#
Power self-check
failed!Please turn
the power back
on!
1 A Blue
1Hz 󽗊ashing
CP disconnection Ready
2 I Blue
2Hz 󽗊ashing
Waiting for IC card
RFID
Waiting
3 B Blue
Stabilization
CP connect to diode+2.7KΩ Connected
4 B Blue
Stabilization
CP connect to diode+1.3KΩ Connected
5 C Green
Green
brightening
CP connect to diode+2.7KΩ
parallelconnect1.3KΩ
Charging
6 D Red
Stabilization
CP connect to diode+2.7KΩparallelconnect1.3KΩ
parallel connect 270R or CP connect to diode+270R
Or CP connect to diode+270R parallel connect 2.7KΩ
Or CP connect to diode+270R parallel connect 1.3KΩ
Fault--2# Need Ventilation!
7 F Red
1Hz 󽗊ashing
CP line short circuit with PE line Fault--3#
CP- PE short
circuit!
Please check the
CP line
8 H Red
5Hz 󽗊ashing
RCMU occurs residual
current or self detect failed
Fault--4#
RCMU leakage or
self-inspection
failure
9 E Red
2Hz 󽗊ashing
Diode short circuit
(Requirement waiting the CP
disconnected)
Fault--5#
EV-Charing
Socket Fault
10 G Blue+Red
2Hz 󽗊ashing
PP line disconnection Fault--6#
SPLIT PP wire，
Please check the
PP line
11 J
Red+Green
+Blue
2Hz 󽗊ashing
Electromagnetic Lock failed Fault--7#
Electronic Lock
Disabled
12 L Blue
5Hz 󽗊ashing
IC card failed Fault--8#
RFID card is not
valid
13 M Red+Green
1Hz 󽗊ashing
Circuit overload，
DLB Mode activated
Fault--9#
Circuit overload，
DLB Mode
activated
