ETH-messtechnik DRVL - DRVL Series Technical Parameters

messtechnik gmbh
20
Model
Torque range
(Nm)
Spring constant C
(Nm/rad)
Mass moment of
inertia J (g x cm²)
Rated axial load
(N) *
Rated radial load
(N) *
DRVL
0,02 16 7 35 30
0,05 16 7 35 30
0,1 16 7 35 30
DRVL-I
0,05 20 10 105 2
0,1 35 10 140 3
0,2 35 10 140 3
0,5 45 10 160 4
1 90 10 210 7
2 135 10 210 13
DRVL-Ib
1 255 30 630 10
2 255 30 630 10
5 715 30 725 25
10 1320 30 725 50
DRVL-II
5 960 100 1200 15
10 2115 100 1300 30
20 3955 100 1300 60
30 5340 105 1300 100
50 6700 105 1300 155
DRVL-III
50 17 x 10
3
775 1800 125
100 30 x 10
3
785 1800 215
150 45 x 10
3
800 1800 340
200 54 x 10
3
810 1800 450
300 67 x 10
3
840 1800 650
DRVL-IV
500 260 x 10
3
9935 4150 650
1000 387 x 10
3
10.140 4150 1275
1300 429 x 10
3
10.285 4150 1650
1500 449 x 10
3
10.380 4150 1700
DRVL-V
2000 1,45 x 10
6
63 x 10
3
4800 1950
3000 1,85 x 10
6
64 x 10
3
4800 2930
4000 2,10 x 10
6
64 x 10
3
4800 3880
5000 2,30 x 10
6
65 x 10
3
4800 4000
DRVL-VI
10.000 8,20 x 10
6
440 x 10
3
11.800 8895
15.000 10,45 x 10
6
448 x 10
3
11.800 9830
20.000 11,80 x 10
6
546 x 10
3
11.800 9830
12.3 Technical Specifications DRVL
Ordering code system
Available Accessories
Supply and display unit: GMV2
ValueMasterBase
Cables
Couplings
A

Standard
n

Speed op�on
w

Angle op�on
- -
-
-
0

Standard accuray
1

Op�on higher accuray
K

Op�on keyway

Model/size

Torque range (Nm)
DRVL
F

Op�on base
-
-
071

Op�on limit frequency 1 kHz
* The values for axial and radial load apply to the non-fixed case
