Ⅷ.Electrical Parameters
1. Performance index
Working Voltage: AC220-240V single phase or 415v 3 phase, 50Hz
Waterproof Level: IPX5
2. Maximum output load index
Heater: AC220V/3.0kw
Jet Pumps: AC220V/3HP
Circulation Pump: AC220V/1HP
Blower: AC220V/1HP
LED Light: AC12V/15W 2 wire or DC12V/15W 4 wire
Ozone: AC12V/8W
Radio: 1) Frequency range: FM87.0~108.0 MHz
2) Max output power: 15W
3) Dual channel loud speaker: 8Ω anti-moisture speaker
4) Digital channels not supported
Ⅸ. Installation Instruction
Please make sure that the control box is orientated correctly to prevent water penetration (Fig. 14).
Fig. 14: The placement of control box
