4-4 Fuel System Parts
Table 4-4. Fuel system parts; please refer to Fig 4-4 for a complete illustration.
No. Code Name of par
Qty each set
1 KS 1710745 M8 x 45 (GB5787-86) Bolt 1
2 KS 17185 Upper fuel tank bracket fastener 1
3 KS 1710208 Flat washer 8 (GB97.1-85) 1
KS 70-1705801 1
KS 78-1705802 1
4
KS 86-1705803
Upper fuel tank bracket
1
5 KS 1705301 Injector 1
6 KS 17212 Hose Clamp 2
7 KS 17192 Fuel Pipe 1
8 KS 17184 Rubber fuel tank mount 4
KS 70-1704201 1
KS 78-1704202 1
9
KS 86-1704203
Fuel Tank
1
10 KS 17212 Fuel Pipe connectors 2
11 KS 17147 Fuel Pipe 1
12 KS 17151 M6 (GB6177-86) Fuel drain gasket 1
13 KS 17152 Fuel drain plug 1
14 KS 17183 Lower fuel tank bracket 1
15 KS 1710714 M6 x 14 (GB5787-86) Bolt 2
16 KS 1710106 M6 (GB6177-86) Nut 2
17 KS 1710206 M6 (GB97.1-85) Flat washer 1
18 KS 17150 Fuel tank cock assembly 1
19 KS 17154 Flat washer 1
20 KS 1719403 Fuel pipe clamp 2
21 KS 17189 Fuel pipe 1
22 KS 17148 Fuel filter gasket 1
KS 70-1704301 1
KS 78-1044302 1
23
KS 86-1704303
Fuel filter assembly
1
KS 70-1704702 1
KS 78-1704702 1
24
KS 86-1704700
Fuel injector pump
1
KS 70-1705601 1
KS 78-1705602 1
25
KS 86-1705603
High pressure fuel pipe
1
26 KS 17146 Fuel cup filter 1
27 KS 17153 Fuel cap assembly 1
28 KS 1705302 Fuel injector cap 1
Note: The fuel tank assembly comes with numbers 9, 10, 11, 12, 13, 16, 17, 18, 19, 22, 23, 26
and 27.
39
