ETQ 178F - Basic Operating Parameters; General Dimensions and Overview of the Generators

7
1-2 Basic operating parameters
1-1.1 Under the given conditions, the generator will output the specified power in the
table listed below.
Table 1.
Height above sea level (ft) Ambient temperature (
o
F) RH
0 +60 (+20
o
C) 60%
<3280.8 (<1000 m) 41~104 (5-40
o
C) 90%
1-3 General dimensions and overview of the generators
1-3.1 General dimensions of the LN series generators
