ETQ 178F - Cooling and Recoil Starting System

4-6 Cooling and recoil starting system
Table 4-6. Please refer to Fig 4-6 for illustration.
No. Code Name of par
t
Qty each set
KS 70-1703401 1
KS 78-1703402 1
1
KS 86-1703404
Recoil case assembly
1
1S KS 78-1703404 178FS case assembly 1
2 KS 1710708 M6 x 8 (GB5787-86) 4
KS 70-1703501 1
KS 78-1703502 1
3
KS 86-1703503
Recoil starter rope
1
KS 70-1703801 1
KS 78-1703802 1
4
KS 86-1703802
Recoil starter handle
1
KS 70/78-1703301 1 5
KS 86-1703303
Flat Torsional spring
1
KS 70-1703201 1
KS 78-1703202 1
6
KS 86-1703203
Recoil reel
1
KS 70-1704003 2 7
KS 78/86-1704005
Starting claw
2
KS 70-17218 1 8
KS 78/86-1721801
Helical spring
1
KS 70-17219 1 9
KS 78/86-1721901
Torsional spring
1
KS 70-1704004 1 10
KS 78/86-1704006
Starting claw plate
1
KS 70-17039 1 11
KS 78/86-1703902
Friction plate
1
KS 70-1703903 1 12
KS 78/86-1703803
Friction plate gasket
1
13 KS 1710306 Spring washer 1
14 KS 1710106 M6 (GB6170-86) Nut 1
15 KS 1710712 M6 x 12 (GB6170-86) 3 or 4
KS 70-1705701 1
KS 78-1705702 1
16
KS 86-1705703
Starter
1
KS 70-1704101 1
KS 78-1704102 1
17
KS 86-1704105
Recoil starter cover
1
17S KS 78-1704106 Recoil starter cover assembly 1
KS 78-1710622 5 18
KS 70/86-1710622
M6 x 22 (GB5787-86) Bolt
4
KS 78-1710207 5 19
KS 70/86-1710207
M6 washer (GB90-85)
4
