 *PLC LAN module,
 *Load Guard device,
 *Magnetic cable holder (different version for longer
cables > 3 m)
EQUIPMENT NEEDE D
 Phillips screwdriver,
 *Hex screwdriver,
 Utility knife,
 Crimping pliers for cable end sleeves,
 Wire strippers, and
 Cable rippers.
*Optional depending on the purchased model
INSTALLATION
PROCEDURE
1
Wall preparation
Measure and mark where to drill the holes for the wall
mounting bracket. Installation height of the wall
mounting bracket should be around 100 cm from the
ground to the bottom of the bracket. This will make the
procedure to insert the cable and to operate the LCD
screen easiest. Make sure that the charging station
holder is attached to the mounting bracket when you are
marking the spots for screws. The holder will prevent any
bending of the mounting bracket so that the holes will
be marked at the correct positions when used.
If power supply cables come through the wall, a hole for
the power supply cables needs to be drilled first.
1-a
You should drill the hole in the position shown on the
picture. The hole should be big enough to manage the
