Operating Instructions
Non-Contact Safety Switch CES-AP-C01-…
14
(Translation of the original operating instructions) 2112663-08-02/20
24 V DC
GND
-F1
Connected
load
Safety
Outputs
Monitoring
Output
Read Head
-B4
UB
2
7
0V
5
DIA
3
OA
4
OB
RST
8
NC
6
NC
1
CES
-S1
Figure 3: Connection example CES-AP-… with reset button
