Delivery Contents
Coupling Requirements
Technical Specications
DANGER!
The tow hitch breaking can cause injury to
people.
The coupling may break as a result of tting the
bicycle carrier on a coupling in a material that is too
soft.
A = Bicycle carrier
B = 2 keys
C = 2 safety straps for front wheels
D = Safety strap for bicycle frame
E = Transport bag
Do not exceed the max. load of the bicycle carrier and the permitted
tongue load of the tow hitch!
The total permitted weight and permitted axle load of the vehicle
must not be exceeded with the bicycle carrier and load.
Material: Steel
Net weight: approx. 18 kg
Max. load: 60 kg
Dimensions (WxHxD): approx. 142 x 70 x 58 cm
Packaging size (WxHxD): approx. 57 x 74 x 25,8 cm
Fit the bicycle carrier only on tow hitches with the following
properties:
Material: ................................. Min. St52 steel or GG52 grey cast iron
Follow the instructions of the coupling manufacturer.
D-value.................................................................... ≥ 7,6 kN
Fit the bicycle carrier only on a coupling made
of St52 steel, GG52 grey cast iron or better
quality.
4
Never t the carrier on a coupling made of
aluminium, other light metals or plastic.
4
Delivery Contents / Technical Specications / Coupling Requirements / Safety Instructions
Safety Instructions
Follow the tting instructions exactly. Not following the instruc-
tions can cause injury to people and damage to property.
If you are unsure when tting, please ask your dealer or the
manufacturer for further information.
Neither the manufacturer nor the dealer is liable for damages due to
improper use or incorrect tting.
Check the bicycle carrier and its load regularly! You have an obliga-
tion to do this and will be held responsible in the case of damage.
WARNING!
WARNING!
NOTE
Personal injury or material damage due to
changed vehicle driving characteristics.
Driving with the mounted bicycle carrier will aect
the driving characteristics of your vehicle.
Personal injury or material damage due to
loss of the bicycles.
Carrying bicycles without using the safety straps
can lead to accidents.
A European operating licence is in place for this
bicycle carrier. It is enclosed with this carrier and
must be carried when the carrier is used.
Adjust your driving speed to the new vehicle
behaa Adjust your speed to the new driving
characteristics. viour.
4
Before the start of every journey, check the
correct and rm attachment of the strap around
the bikes and the U-shaped bracket of the
carrier (see Step 9).
4
Before the start of every journey, check the
correct and rm attachment of both straps
around the front wheel, and the strap around
the rear wheel of the bicycle.
4
Before the start of every journey, check that the
straps are not worn or damaged.
4
Worn or damaged straps must be replaced with
undamaged straps before the start of the jour-
ney. The straps used must be approved by EAL
GmbH.
4
Tighten the straps if necessary.
4
Avoid sudden and jerky steering movements.
4
Remember that your vehicle is longer than
usual.
4
Never drive faster than 130 km/h.
4
