EUFAB RAVEN User Manual

31
Spare parts overview - Table
No.
Spare part
no.
Quantity Part designation
1 pre-assembled 1
U - bracket
and Basic carrier
2 90251 1 U-washer M6
3 90799 1 Quick-fastener
4 90321 1 U-washer M10
5 pre-assembled 1 Bolt ø 10 mm
6 pre-assembled 1 Socket-head bolt M10 x 80 mm
7 90320 1 Self-locking nut M10
8 90321 1 U-washer M10
9 pre-assembled 1 Guide eye
10 pre-assembled 1 Quick-fastener tension spring
11 pre-assembled 1 Socket-head bolt M6 x 80 mm
12 90604 4 Steel wheel rail
13 pre-assembled 4 Support table end-cap
14 pre-assembled 2 Plastic carrying handle
15 90666 4 Wheel blocker, pre-assembled
16 90605 8 Wheel rail end-cap
17 90716 1
Support table right with
registration plate holder
18 90254 2 U-washer M5
19 vormontiert 4 Bolt M5 x 50 mm
20 vormontiert 4 Cap nut M5
21 vormontiert 4 Cap nut M5
22 vormontiert 2 Lamp holder bracket
23 11500 1 Tinted glass right
24 90414 1 Registration plate holder
25 90321 8 U-washer M10
26 90254 4 U-washer M5
27 90250 1 Selbstsichernde Mutter M5
28 90320 4 Self-locking nut M10
29 90250 2 Self-locking nut M5
30 90405 1 Bolt M5 x 25 mm
31 vormontiert 1 Unlocking lever
32 vormontiert 1 Locking catch
No.
Spare part
no.
Quantity Part designation
33 90251 1 U-washer M6
34 90253 1 Self-locking nut M6
35 pre-assembled 1 Clamping lever
36 pre-assembled 1 Locking catch knob
37 90675 4 Nut cover cap M10
38 pre-assembled 4 Hinge protector
39 pre-assembled 4 Socket-head bolt M10 x 30 mm
40 pre-assembled 4 Socket-head bolt M8 x 25 mm
41 pre-assembled 4 Nut M8
42 pre-assembled 1
Registration plate holder
Riveted to Part 17
43 90422 2 Bolt M5 x 10 mm
44 pre-assembled 4 Bolt M5 x 55 mm
45 pre-assembled 4 Sleeve M5 x 35 mm
46 pre-assembled 4 Rear light holder Retaining arm
47 11503 1 Rear left tinted glass light
48 90717 1 Support table left
49 90551 8 Fixing bolt M6 x 20 mm
50 90230 4 Fixing strap small
51 90251 8 U-washer M6
52 90515 8 Wing nut M6
53 90224 1 Safety strap in accessory bag
54 11231 1 Frame holder long
55 11230 1 Frame holder short
56 90500 1 Allen key M5 in accessory bag
57 90230 2
Fixing strap small
in accessory bag
58 90715 1 EGBE in accessory bag
59 90754 1 Bag
60 11502 1 Lamp right
61 11501 1 Tinted glass left
62 11504 1 Lamps complete with cable
63 11505 1 Cable harness for rear lights
