REVERSE DOOR (Optional) (Cont .)
11.Remove the 2 screws from the left side and relocate to the right side and replace the plastic
locker on the fresh food door and freezer door bottom in the spare bag.
12.Remove the two plug buttons on the left side at the center and install them on the right side.
13.Turn and relocate the center hinge to the left side and reinsert the screws. Do not tighten
screws yet.
14.Align the fresh food door on the left center hinge. With the magnetic gasket holding the
door in place, make sure that the door is aligned with the refrigerator, and secure the bottom
hinge on the left side with 3 screws.
15.Ensure that the fresh food door is properly sealed and levelled before tightening the center
hinge screws and the bottom hinge screws.
16.Lift the refrigerator to an upright position.
17.Place the freezer door on the center hinge over the pin. Ensure that the door is aligned
horizontally and vertically, and that the gasket seals on all sides.
18.Turn and relocate the top hinge on the left side with screws.
19.Replace the hinge cover on top of the hinge by sliding it from front to back.
20.Put the 2 plug buttons on the right side on top of the cabinet.
21.Open and close both the freezer and fresh food doors several times to ensure that each door
is positioned correctly and that the gasket is sealed tightly. If it isn’t, please adjust the door
again.
22.Wait at least 30 minutes before plugging in the refrigerator to allow the refrigerant to settle
down. Then plug in the unit.
Door Alignment
Freezer Door: (see fig. #1)
1.Remove the top hinge cover.
2.Loosen the top hinge screws using a phillips head screwdriver.
3.Adjust the door or put a spacer in between and then tighten the screws.
4.Replace the top hinge cover.
fig. # 1
Installation Instructions
08
