Euphonix ML530 Mic-Line Interface Operation Manual
11
Specifications
Table 1 Performance Specifications
Table 2 Environmental and Power Specifications
Gain Range -12 dB to 72 dB in 0.5 dB increments
Phantom Power +48 V ±2% (Switched per channel)
Maximum Input Level 41 dB (Pad inserted, unity gain, @1 kHz, @1% THD+N)
Differential Input Impedance
200 k (Hi Z, Pad off, +48V off)
200 k (Hi Z, Pad on, +48V off)
12.7 k (Hi Z, Pad on, +48V on)
12.7 k (Hi Z, Pad off, +48V on)
1.5 k (Lo Z, Pad off, +48V off)
1.5 k (Lo Z, Pad on, +48V off)
1.4 k (Lo Z, Pad on, +48V on)
1.4 k (Lo Z, Pad off, +48V on)
Maximum Output Level 29 dB (@1 kHz, @1% THD+N)
Output Impedance 100
Frequency Response
10 Hz – 60 kHz (-0.5 dB @ unity gain)
10 Hz – 50 kHz (-0.5 dB @ 30 dB gain)
10 Hz – 40 kHz (-0.5 dB @ 66 dB gain)
Gain Accuracy ±0.15 dB (@1 kHz)
Distortion (THD+N)
0.004% (@ 1 kHz @ 0 dB gain with
+13.5 dB applied, 22 kHz filtered)
< 0.02% (20 Hz – 20 kHz @ 13.5 dB 80 kHz filtered)
Equivalent Input Noise (EIN) -127 dB (@66 dB gain, 22 Hz – 22 kHz filtered, Low Z mode, 150 source)
Common Mode Rejection (CMR) >50 dB (10 Hz – 20 kHz)
Phase Linearity ±10° (25 Hz – 20 kHz)
High-pass Filter 80 Hz 18 dB/octave switched per channel
Phase Invert 180° switched per channel
Operating Temperature 5–35°C
Power Requirements 90–250 VAC, 50/60Hz
Power Consumption 100 W
