Euphonix ML530 Mic-Line Interface Operation Manual
14
Figure 5 ML530 Standard Configuration
12 male XLR to one
male Elco 38
Mic/Line Analog Out
MADI out to
Studio Hub
1
AES/EBU Sync In
from Sync DA
2
Control from PC253i
Interface Pilot
AM713
MADI
OUT
4 4
3
5, 6
Elco crimp pins and hoods for user
inputs are supplied in accessory
cable kits. Input cabling supplied by
customer
