EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
43/56
7-channel mode: Small mode in which the brightness of all spots together as well as different programs for
the derby, the scanners and the UV LEDs can be called up.
Channel Value Function
1
000‒255 Red 0-100%
Spots
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 White 0-100%
5
Derby
000–005 No function
006–055 Program 1 slow > fast
056–105 Program 2 slow > fast
106–155 Program 3 slow > fast
156–205 Program 4 slow > fast
206–255 Program 5 slow > fast
6
Scanner
000–005 No function
006–031 Pan /Tilt program 1
032-063 Pan /Tilt program 2
064-095 Pan /Tilt program 3
096-127 Pan /Tilt program 4
128-159 Pan /Tilt program 5
160-191 Pan /Tilt program 6
192-223 Pan /Tilt program 7
224-255 Pan /Tilt program 8
7
UV Strobe
000–005 No function
006–010 On
011–255 Strobe effect slow > fast
13-channel mode: In this mode, the spots and derby are controlled together in terms of color, and the
scanners can be controlled together in all functions.
Channel Value Function
1
000‒255 Red 0-100%
Spots and Derby
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 White 0-100%
5
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
6
Scanner Pan
000–255 Pan movement
7
Scanner Tilt
000–255 Tilt movement
8
Scanner Pan/Tilt
000–255 Pan/Tilt speed fast > slow
9
Scanner Colors
000–015 White
016–031 Blue
032–047 Orange
048–063 Red
064–079 Light blue
080–095 Light yellow
096–111 Light green
112–127 Magenta
128–143 White + blue
144–159 Orange + red
160–175 Light blue + light yellow
176–191 Light green + magenta
192–207 White + orange
208–223 Blue + red
224–239 Light blue + light green
240–255 Light yellow + magenta
10
Scanner Gobos
000–015 Gobo 1
016–031 Gobo 2
032–047 Gobo 3
