EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
44/56
048–063 Gobo 4
064–079 Gobo 5
080–095 Gobo 6
096–111 Gobo 7
112–127 Gobo 8
128–143 Gobo 1 + Gobo 2
144–159 Gobo 3 + Gobo 4
160–175 Gobo 5 + Gobo 6
176–191 Gobo 7 + Gobo 8
192–207 Gobo 1 + Gobo 8
208–223 Gobo 2 + Gobo 7
224–239 Gobo 3 + Gobo 6
240–255 Gobo 4 + Gobo 5
11
Scanner Dimmer
000‒255 Total brightness 0-100%
12
Strobe Effect
000–003 On
004–007 Off
008–076 Strobe effect slow > fast
077–145 Pulsating strobe effect slow > fast
146–215 Random strobe effect slow > fast
216–255 On
13
UV Dimmer
000‒255 Total brightness 0-100%
14-channel mode: Two spots and the Derby can be controlled separately, and different programs can be
called up for the scanners. This mode is ideal for the Eurolite Colorchief.
Channel Value Function
1
000‒255 Red 0-100%
Spots 1 + 4
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 White 0-100%
5
000‒255 Red 0-100%
Spots 2 + 3
6
000‒255 Green 0-100%
7
000‒255 Blue 0-100%
8
000‒255 White 0-100%
9
000‒255 Red 0-100%
Derby
10
000‒255 Green 0-100%
11
000‒255 Blue 0-100%
12
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
13
Scanner
000–005 No function
006–031 Pan /Tilt program 1
032-063 Pan /Tilt program 2
064-095 Pan /Tilt program 3
096-127 Pan /Tilt program 4
128-159 Pan /Tilt program 5
160-191 Pan /Tilt program 6
192-223 Pan /Tilt program 7
224-255 Pan /Tilt program 8
1
4
UV Dimmer
000‒255 Total brightness 0-100%
