15-channel mode: Like 13-channel mode but the general automatic and music controlled programs can also
be called up.
Channel Value Function
1
000‒255 Red 0-100%
Spots and Derby
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 White 0-100%
5
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
6
Scanner Pan
000–255 Pan movement
7
Scanner Tilt
000–255 Tilt movement
8
Scanner Pan/Tilt
000–255 Pan/Tilt speed fast > slow
9
Scanner Colors
000–015 White
016–031 Blue
032–047 Orange
048–063 Red
064–079 Light blue
080–095 Light yellow
096–111 Light green
112–127 Magenta
128–143 White + blue
144–159 Orange + red
160–175 Light blue + light yellow
176–191 Light green + magenta
192–207 White + orange
208–223 Blue + red
224–239 Light blue + light green
240–255 Light yellow + magenta
10
Scanner Gobos
000–015 Gobo 1
016–031 Gobo 2
032–047 Gobo 3
048–063 Gobo 4
064–079 Gobo 5
080–095 Gobo 6
096–111 Gobo 7
112–127 Gobo 8
128–143 Gobo 1 + Gobo 2
144–159 Gobo 3 + Gobo 4
160–175 Gobo 5 + Gobo 6
176–191 Gobo 7 + Gobo 8
192–207 Gobo 1 + Gobo 8
208–223 Gobo 2 + Gobo 7
224–239 Gobo 3 + Gobo 6
240–255 Gobo 4 + Gobo 5
11
Scanner Dimmer
000‒255 Total brightness 0-100%
12
Strobe Effect
000–003 On
004–007 Off
008–076 Strobe effect slow > fast
077–145 Pulsating strobe effect slow > fast
146–215 Random strobe effect slow > fast
216–255 On
13
UV-Dimmer
000‒255 Total brightness 0-100%
14
Preset Programs
000–005 No function
006–017 Automatic / sound program 1
018–030 Automatic / sound program 2
031–042 Automatic / sound program 3
043–056 Automatic / sound program 4
057–069 Automatic / sound program 5
