EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
46/56
070–082 Automatic / sound program 6
083–095 Automatic / sound program 7
096–108 Automatic / sound program 8
109–121 Automatic / sound program 9
122–134 Automatic / sound program 10
135–147 Automatic / sound program 11
148–160 Automatic / sound program 12
161–173 Automatic / sound program 13
174–186 Automatic / sound program 14
187–199 Automatic / sound program 15
200–212 Automatic / sound program 16
213–225 Automatic / sound program 17
226–238 Automatic / sound program 18
239–251 Automatic / sound program 19
252–255 Automatic / sound program 20
15
Automatic Mode/
Sound Control
000–100 Automatic program with color switch slow > fast
101–200 Automatic program with color fade slow > fast
201–225 Sound program with color switch
226–255 Sound program with color fade
Note: Channels 1-3 are available only if channel 14 is set to a value 000-005.
18-channel mode: Two spots and the Derby can be controlled separately; the scanner can combine
different movement programs with individually adjustable colors and gobos.
Channel Value Function
1
000‒255 Red 0-100%
Spots 1 + 4
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 White 0-100%
5
000‒255 Red 0-100%
Spots 2 + 3
6
000‒255 Green 0-100%
7
000‒255 Blue 0-100%
8
000‒255 White 0-100%
9
000‒255 Red 0-100%
Derby
10
000‒255 Green 0-100%
11
000‒255 Blue 0-100%
12
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
13
Scanner
000–005 No function
006–031 Pan /Tilt program 1
032-063 Pan /Tilt program 2
064-095 Pan /Tilt program 3
096-127 Pan /Tilt program 4
128-159 Pan /Tilt program 5
160-191 Pan /Tilt program 6
192-223 Pan /Tilt program 7
224-255 Pan /Tilt program 8
14
Scanner Colors
000–015 White
016–031 Blue
032–047 Orange
048–063 Red
064–079 Light blue
080–095 Light yellow
096–111 Light green
112–127 Magenta
128–143 White + blue
144–159 Orange + red
160–175 Light blue + light yellow
176–191 Light green + magenta
192–207 White + orange
208–223 Blue + red
224–239 Light blue + light green
240–255 Light yellow + magenta
