EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
48/56
30-channel mode: Spots and Derby can be controlled separately, the two scanners are controlled together.
Channel Value Function
1
000‒255 Red 0-100%
Spot 1
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 White 0-100%
5
000‒255 Red 0-100%
Spot 2
6
000‒255 Green 0-100%
7
000‒255 Blue 0-100%
8
000‒255 White 0-100%
9
000‒255 Red 0-100%
Spot 3
10
000‒255 Green 0-100%
11
000‒255 Blue 0-100%
12
000‒255 White 0-100%
13
000‒255 Red 0-100%
Spot 4
14
000‒255 Green 0-100%
15
000‒255 Blue 0-100%
16
000‒255 White 0-100%
17
000‒255 Red 0-100%
Derby
18
000‒255 Green 0-100%
19
000‒255 Blue 0-100%
20
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
21
Dimmer
Spots + Derby
000‒255 Total brightness 0-100%
22
Strobe Effect
000–005 No function
006–055 Strobe effect 1 slow > fast
056–105 Strobe effect 2 slow > fast
106–155 Strobe effect 3 slow > fast
156–205 Strobe effect 4 slow > fast
206–255 Strobe effect 5 slow > fast
23
Scanner Pan
000–255 Pan movement
24
Scanner Tilt
000–255 Tilt movement
25
Scanner Pan/Tilt
000–255 Pan/Tilt speed fast > slow
26
Scanner Colors
000–015 White
016–031 Blue
032–047 Orange
048–063 Red
064–079 Light blue
080–095 Light yellow
096–111 Light green
112–127 Magenta
128–143 White + blue
144–159 Orange + red
160–175 Light blue + light yellow
176–191 Light green + magenta
192–207 White + orange
208–223 Blue + red
224–239 Light blue + light green
240–255 Light yellow + magenta
27
Scanner Gobos
000–015 Gobo 1
016–031 Gobo 2
032–047 Gobo 3
048–063 Gobo 4
064–079 Gobo 5
080–095 Gobo 6
096–111 Gobo 7
112–127 Gobo 8
128–143 Gobo 1 + Gobo 2
