EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
49/56
144–159 Gobo 3 + Gobo 4
160–175 Gobo 5 + Gobo 6
176–191 Gobo 7 + Gobo 8
192–207 Gobo 1 + Gobo 8
208–223 Gobo 2 + Gobo 7
224–239 Gobo 3 + Gobo 6
240–255 Gobo 4 + Gobo 5
28
Scanner Dimmer
000‒255 Total brightness 0-100%
29
Strobe Effect
000–003 On
004–007 Off
008–076 Strobe effect slow > fast
077–145 Pulsating strobe effect slow > fast
146–215 Random strobe effect slow > fast
216–255 On
30
UV Dimmer
000‒255 Total brightness 0-100%
32-channel mode: Like 30-channel mode but the automatic and music controlled programs can also be
called up.
Channel Value Function
1
000‒255 Red 0-100%
Spot 1
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 Red 0-100%
5
000‒255 Red 0-100%
Spot 2
6
000‒255 Green 0-100%
7
000‒255 Blue 0-100%
8
000‒255 Red 0-100%
9
000‒255 Red 0-100%
Spot 3
10
000‒255 Green 0-100%
11
000‒255 Blue 0-100%
12
000‒255 Red 0-100%
13
000‒255 Red 0-100%
Spot 4
14
000‒255 Green 0-100%
15
000‒255 Blue 0-100%
16
000‒255 Red 0-100%
17
000‒255 Red 0-100%
Derby
18
000‒255 Green 0-100%
19
000‒255 Blue 0-100%
20
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
21
Dimmer
Spots + Derby
000‒255 Total brightness 0-100%
22
Strobe-Effekt
000–005 No function
006–055 Strobe effect 1 slow > fast
056–105 Strobe effect 2 slow > fast
106–155 Strobe effect 3 slow > fast
156–205 Strobe effect 4 slow > fast
206–255 Strobe effect 5 slow > fast
23
Scanner Pan
000–255 Pan movement
24
Scanner Tilt
000–255 Tilt movement
25
Scanner Pan/Tilt
000–255 Pan/Tilt speed fast > slow
26
Scanner Colors
000–015 White
016–031 Blue
032–047 Orange
048–063 Red
