EuroLite LED KLS Scan Next FX User Manual

00132156, Version 1.0
51/56
39-channel mode: Separate control of the four spots, the derby and the two scanners; the automatic and
sound-controlled programs can also be called up.
Channel Value Function
1
000‒255 Red 0-100%
Spot 1
2
000‒255 Green 0-100%
3
000‒255 Blue 0-100%
4
000‒255 Red 0-100%
5
000‒255 Red 0-100%
Spot 2
6
000‒255 Green 0-100%
7
000‒255 Blue 0-100%
8
000‒255 Red 0-100%
9
000‒255 Red 0-100%
Spot 3
10
000‒255 Green 0-100%
11
000‒255 Blue 0-100%
12
000‒255 Red 0-100%
13
000‒255 Red 0-100%
Spot 4
14
000‒255 Green 0-100%
15
000‒255 Blue 0-100%
16
000‒255 Red 0-100%
17
000‒255 Red 0-100%
Derby
18
000‒255 Green 0-100%
19
000‒255 Blue 0-100%
20
Derby Motor
000 Stop
001–127 Clockwise rotation slow > fast
128 Stop
129–255 Counter clockwise rotation slow > fast
21
Dimmer
Spots + Derby
000‒255 Total brightness 0-100%
22
Strobe Effect
000–005 No function
006–055 Strobe effect 1 slow > fast
056–105 Strobe effect 2 slow > fast
106–155 Strobe effect 3 slow > fast
156–205 Strobe effect 4 slow > fast
206–255 Strobe effect 5 slow > fast
23
Scanner Pan
000–255 Pan movement
Scanner 1
24
Scanner Tilt
000–255 Tilt movement
25
Scanner Pan/Tilt
000–255 Pan/Tilt speed fast > slow
26
Scanner Colors
000–031 White
032–063 Blue
064–095 Orange
096–127 Red
128–159 Light blue
160–191 Light yellow
192–223 Light green
224–255 Magenta
27
Scanner Gobos
000–031 Gobo 1
032–063 Gobo 2
064–095 Gobo 3
096–127 Gobo 4
128–159 Gobo 5
160–191 Gobo 6
192–223 Gobo 7
224–255 Gobo 8
28
Scanner 1 Dimmer
000‒255 Total brightness 0-100%
29
Strobe Effect
000–003 On
004–007 Off
008–076 Strobe effect slow > fast
077–145 Pulsating strobe effect slow > fast
146–215 Random strobe effect slow > fast
216–255 On
