TECHNICAL SPECIFICATIONS
Power supply: 5 V DC phantom power
Carrier frequency: 2.4 GHz ISM band, 78 channels
Modulation: GFSK
Transmission power: max. 18 dBm
Coverage: 400 m (line-of-sight)
Parallel operation: max. 6 transmitters
QuickDMX connection: USB, type A
DMX channels: 1 universe (512 channels)
Dimensions with antenna: 86 x 40 x 11 mm
Weight: 15 g
Occupation of the USB plug:
Accessories
No. 70064700 EUROLITE QuickDMX Wireless Transmitter
No. 70064701 EUROLITE QuickDMX Wireless Receiver
No. 70064702 EUROLITE QuickDMX Wireless receiver
phantom-power
No. 70064703 EUROLITE QuickDMX Wireless
Transmitter/Receiver

EuroLite QuickDMX Specifications

General

Type	Wireless DMX Transceiver
Frequency band	2.4 GHz
DMX channels	512
Power supply	5V DC, 500mA
DMX Output	1 x 3-pin XLR
DMX Input	1 x 3-pin XLR
Connectors	3-pin XLR
