EuroMini 10V6.e - The Tamper Spring and Connections

Page:8 Castle Care-Tech
O
verview
Tamper Connections
The Tamper Spring and Connections
BELL
BUS
BATTERY
AUX
Remove for DP
PGM AUX+ SPK STB BELL TR B- B+
Tamper
Connection
Tamper
Spring
Z1 COM Z2 COM +12V Z3 COM Z4 Z5 COM Z6 COM +12V Z7 COM Z8 Z9 COM Z10 D1- D2+ D3 D4 - BAT + GND
The EURO mini printed circuit board is protected by a metal casing. The lid is
tampered by a spring that is connected to the printed circuit board.
To disable the tamper spring, simply link out the tamper connections shown
below.
