Note: For multi-cell units, the inlet pressure shown is per cell.
** Not available as eco-ATWE
Table 5 - Required Recirculating Water Inlet Pressure for Remote Sump Application - Coil Products Only
Evaporative Condenser Closed Circuit Cooler Required Inlet
Model Number Footprint Pressure (psi)
ATC-E Products eco-ATC-A Products ATWB, eco-ATW &
eco-ATWE Products
50E to 165E 122A to 263A 3’ and 4’ wide units** 2.0
170E to 247E 160A to 326A 8.5’x7.5’ 2.0
218E to 305E 205A to 504A 8.5’x9’ 2.0
246E to 473E 395A to 671A 8.5’x10.5’, 8.5’x12’, 8.5’x14’ 2.0
486E to 630E 451A to 804A 8.5’x18’ 3.0
508E to 755E 444A to 1013A 8.5’x21’ 4.0
6
43E to 950E 441A to 988A 8.5’x24’, 28’ 2.5
639E to 926E 300-501A to 642-1002A 17’x12’, 17’x14’ 2.5
XE298E to XC462E, XE596E to XC925E 391-694A to 879-1388A 10’x12’, 10’x24’, 20’x12’ 3.7
XE406E to XC669E, XE812E to XC1340E 325 to 632A, 408 to 685A, 432 to 923A 10’x18’, 10’x36’, 20’x18’ 5.7
428E to 892E 650 to 1263A, 770 to 1369A, 1020 to 1847A 12’x12’, 12’x14’, 12’x18’ 3.5
858E to 1784E 710 to 1264A, 816 to 1370A, 1021 to 1848A 12’x24’ 12x28’, 12’x36’ 2.5
857E to 1783E 1293 to 2515A, 1493 to 2654A, 2182 to 3583A 24’x12, 24’x14’, 24’x18’ 3.0
1879E to 3459E 585 to 1001A, 1120 to 1993A 24’x24’, 24’x28’, 24’x36’ 2.5
791E to 967E, 1625E to 1925E 1159 to 1983A, 2247 to 3846A 12’x20’, 12’x40’ 3.5
1616E to 1915E, 2855E to 3714E 24’x20’, 24’x40’ 3.5
CATC Products CATW Products
181 thru 373 7.5’x8’, 7.5’x12’, 7.5’x14’ 2.0
362 thru 504 7.5’x18’ 3.0
LRC Products LRWB Products
25 to 72 3’ wide units 1.0
76 to 114 5’x6’ 2.0
108 to 183 5’x9’ 2.0
190 to 246 5’x12’ 2.0
188 to 379 8’ wide units 2.0
LSC-E Products LSWE Products
36 to 80 4’x6’ 1.5
90 to 120 4’x9’ 1.5
135 to 170 4’x12’, 4’x18’ 1.5
185 to 385 5.5’x12’, 5.5’x18’ 2.0
400 to 1610 10’x12’, 10’x18’, 10’x24’, 10’x36’ 2.5
8’x12’, 8’x18’, 8’x24’, 8’x36’ 3.0
ESWA/ESW4 Products
8.5’x6’ 3.0
8.5’x9’ 2.5
8.5’x12’ 2.5
— 8.5’x18’ 3.0
12’x12’ 2.0
12’x18’ 3.0
14’x22’ 2.0
PMC-E Products eco-PMC Products
175E to 375E 183 to 387 2.0
332E to 1586E 275 to 1662 — 4.0
420E to 2019E 314 to 2191 3.5
PHC Products
S208 to S411 (12’x12’), L403 to L842 (12’x24’) 3.0
S416 to S822 (12’x24’) 3.0
5373 to 5541 (12’x18’), 5746 to 51182 (12’x36’) — 4.0
D621 to D858 (12’x24’), D1241 to D1716 (24’x24’) 5.0
D790 to D1025 (14’x26’) 4.5
D1580 to D 2050 (28’x28’) 4.5
