39
FAN & COIL CASING SECTION
PAN SECTION
FRAMED AIR
INLET LOUVER
LOUVER RETAINER
AIR INLET LOUVER MEDIA
COLD WATER BASIN
FAN CYLINDER
FAN SCREEN
FAN
F
AN SCREEN SUPPORT
A
CCESS DOOR
COIL
COIL CONNECTIONS
SWING OUT
MOTOR COVER
eco-ATWB-E 8.5’ Wide Units
